Approx. 35.9 x 24.0 mm CMOS

Approx. 26.2 megapixels

Approx. 27.1 megapixels

3:2

Built in/Fixed

EOS integrated cleaning system

Primary Colour

DIGIC 7

EF (excludes EF-S, EF-M lenses)

Equivalent to 1.0x the focal length of the lens

Optical Image Stabilizer on compatible lens
Movie: In-camera 5-axis Digital IS available.1

Via optical viewfinder:
TTL secondary image-forming phase detection system with AF dedicated sensor
Via liveview on LCD screen:
Dual Pixel CMOS AF System. Phase detection pixels built onto imaging sensor2

Via optical viewfinder:
45 cross-type AF points
(45 f/5.6 cross-type AF points, up to 27 f/8 (9 cross-type) points3,  centre point is f/2.8 and f/5.6 dual cross-type and sensitive to -3 EV)
The number of available cross-type AF points will differ depending on the lens.
Via liveview on LCD screen:
Maximum 63 AF points (Fixed location on 9x7 grid) via camera automatic selection4

Via optical viewfinder:
EV -3 - 18 (at 23 °C & ISO 100) with centre AF point & f/2.8 or brighter lenses
Via liveview on LCD screen:
EV -2.5- 18 (at 23 °C & ISO 100) with One-Shot AF

Via optical viewfinder:
One Shot AF
Predictive AI Servo AF (AI Servo II algorithm)
AI Focus AF
Via liveview on LCD screen:
One-Shot AF
Servo AF

Via optical viewfinder:
Automatic selection: 45 point AF
Manual selection: Single point/ Spot AF
Manual selection: Zone AF
Manual selection: Large Zone AF
AF points can be selected separately for vertical and horizontal shooting
Via LCD screen:
Automatic selection: Face AIAF + Tracking, up to 63 AF points when no subject/ face detected
Manual selection via touch screen or freely position 1 AF point/ 1 AF Zone (9 points, 3x3 grid).5

Superimposed in viewfinder and indicated on top LCD panel and Quick Control screen

Yes6

Locked when shutter button is pressed half way in One Shot AF mode or AF-ON Button is pressed.

Emitted by an optional dedicated Speedlite or optional Speedlite Transmitter ST-E2

Selected on lens

C.Fn II-16
+/- 20 steps (wide and tele setting for Zooms)
Adjust all lenses by same amount
Adjust up to 40 lenses individually
Adjustments remembered for lens by serial number

Via optical viewfinder:
7560-pixel RGB+IR metering sensor
Metering with the area divided into 63 segments (9 × 7)
(1) Evaluative metering (linked to all AF points)
(2) Partial metering (approx. 6.5 % of viewfinder)
(3) Spot metering (approx. 3.2 % of viewfinder)
(4) Center-weighted average metering
Via liveview on LCD screen:
(1) Evaluative metering (315 zones)
(2) Partial metering (approx. 6.3 % of LCD screen)
(3) Spot metering (approx. 2.7 % of LCD screen)
(4) Center-weighted average metering

Via optical viewfinder:
EV 1-20 (at 23 °C , ISO 100)
Via liveview on LCD screen:
EV 0-20 (at 23 °C, ISO 100, evaluative metering)

Auto: In 1-shot AF mode with evaluative metering exposure is locked when focus is achieved.
Manual: By AE lock button in creative zone modes.

+/-5 EV in 1/3 or 1/2 stop increments (can be combined with AEB).

2, 3, 5 or 7 Shots +/-3 EV 1/3 or 1/2 stop increments

Stills: Auto (100 - 40000), 100 - 40000 (in 1/3-stop or whole stop increments), Manual ISO can be expanded to L: 50, H1: 51200, H2: 1024007
Movie: Auto (100 - 25600), 100 - 25600 (in 1/3-stop or whole stop increments), Auto ISO/ Manual ISO settings can be expanded to H1: 51200. H2: 1024008

Electronically-controlled focal-plane shutter

30-1/4000 sec (1/2 or 1/3 stop increments), Bulb (Total shutter speed range. Available range varies by shooting mode)

Auto white balance with the imaging sensor

AWB (Ambeince priority/White priority), Daylight, Shade, Cloudy, Tungsten, White Fluorescent light, Flash, Custom, Colour Temperature Setting (Approx. 2500 K - 10000 K)
White balance compensation:
1. Blue/Amber +/-9
2. Magenta/ Green +/-9.

Yes, 1 setting can be registered

+/-3 levels in single level increments
2, 3, 5 or 7
Selectable Blue/Amber bias or Magenta/ Green bias.

Pentaprism

Approx. 98 %

Approx. 0.71x9

Approx. 21mm (from eyepiece lens centre)

-3 to +1 m-1 (dioptre)

Fixed (Transmissive LCD screen)

Quick-return half mirror (Transmission: reflection ratio of 40:60, no mirror cut-off with EF600mm f/4 or shorter)

AF information: AF points, focus confirmation, AF area selection mode, AF mode
Exposure information: Exposure mode, Shutter speed, aperture value, ISO speed, AE lock, exposure level/compensation, Metering mode, spot metering circle, exposure warning, AEB.
Flash information: Flash ready, high-speed sync, FE lock, flash exposure compensation, red-eye reduction light.
Image information: Card information, maximum burst (2 digit display), Highlight tone priority (D+).
Composition information: Grid, Electronic level, Aspect Ratio
Other information: Drive mode, Battery level, Alert symbol, Flicker Detection, Image Quality (RAW/ JPEG)

Yes, with Depth of Field preview button.

On strap

Touch screen Vari angle 7.7cm (3.0") 3:2 Clear View II TFT, approx. 1040K dots

Approx. 100%

Approx. 170°

Anti smudge

Adjustable to one of seven levels

(1) Quick Control Screen
(2) Camera settings
(3) Electronic Level

E-TTL II Auto Flash, Metered Manual

1/180 sec

+/- 3EV in 1/2 or 1/3 increments

Yes, with compatible External Flash

Yes

Yes

Yes/ No

E-TTL II with EX series Speedlites, wireless multi-flash support (with optional accessory)

via camera menu screen

Scene Intelligent Auto, Creative Auto, Special Scene (Portrait, Group Photo, Landscape, Sports, Kids, Panning10, Close-up, Food, Candlelight, Night Portrait, Handheld Night Scene, HDR Backlight Control), Program AE, Shutter-priority AE, Aperture-priority AE, Manual exposure, Bulb exposure, Custom (C1/C2)

Auto, Standard, Portrait, Landscape, Fine Detail, Neutral, Faithful, Monochrome, User Defined (x3)

sRGB and Adobe RGB

Highlight Tone Priority
Auto Lighting Optimizer (4 settings)
Long exposure noise reduction
High ISO speed noise reduction (4 settings + Multi Shot Noise Reduction)
Auto Correction of Lens Peripheral illumination, Distortion correction, Chromatic aberration correction and Diffraction correction
Multi-exposure
HDR Mode
RAW image processing - during image Playback only
Resize to M or S1, S2

Single, Continuous L, Continuous H, Self timer (2s + Remote, 10s + Remote, Continuous), Silent single shooting, Silent continuous shooting

Max. Approx. 6.5 fps. (speed maintained for up to 150 images in JPEG, 21 images in RAW)1112

Built-in, number of shots selectable from 1-99 or unlimited. Bulb timer available
Timelapse Movie mode available13

Electronic viewfinder with image sensor

Approx. 100% (horizontally and vertically)

29.97 fps

Manual Focus (Magnify the image 5x or 10x at any point on screen)
Autofocus: Dual Pixel CMOS AF14, Tracking sensitivity (-3 to +3) and Movie Servo AF Speed (-7 to +2)

Real-time evaluative metering with image sensor
Active metering time can be changed

Grid overlay (x3), Histogram, Aspect ratios, Electronic Level

JPEG: Fine, Normal (Exif 2.30 [Exif Print] compliant) / Design rule for Camera File system (2.0),
RAW: RAW, M-RAW, S-RAW (14bit, Canon original RAW 2nd edition),
Digital Print Order Format [DPOF] Version 1.1 compliant

Yes, any combination of RAW + JPEG, M-RAW + JPEG, S-RAW + JPEG possible.

JPEG 3:2: (L) 6240 x 4160, (M) 4160 x 2768, (S1) 3120 x 2080 (S2) 2400 x 1600
JPEG 4:3: (L) 5536 x 4160, (M) 3680 x 2768, (S1) 2768 x 2080, (S2) 2112 x 1600
JPEG 16:9: (L) 6240 x 3504, (M) 4160 x 2336, (S1) 3120 x 1752, (S2) 2400 x 1344
JPEG 1:1: (L) 4160 x 4160, (M) 2768 x 2768, (S1) 2080 x 2080, (S2) 1600 x 1600
RAW: (RAW) 6240 x 4160, (M-RAW) 4680 x 3120, (S-RAW) 3120 x 2080

MP4:
Movie: MPEG4 AVC / H.264 (Video: H.264 inter frame, Sound: Linear PCM / AAC, recording level can be manually adjusted by user)
MOV:
Motion JPEG (4K 29.97/25.00, time-lapse movies only)
ALL-I (FHD 29.97/25.00, time-lapse movies only)

1920 x 1080 (59.94, 50, 29.97, 25, 23.976 fps) IPB Standard or Light
1280 x 720 (59.94, 50, 29.97, 25 fps) IPB Standard or Light
HDR movie15:
1920 x 1080 (59.94, 50, 29.97, 25, 23.976 fps) IPB (Standard, Light)
Time-lapse movie:
3840 x 2160 ( 29.97, 25 fps) Motion JPEG
1920 x 1080 ( 29.97, 25 fps) ALL-I

Max duration 29min 59sec, Max file size 4GB (If file size exceeds 4GB a new file will be created automatically except in Timelapse Movie mode)

New folders can be manually created and selected

(1) Consecutive numbering
(2) Auto reset
(3) Manual reset

28 Custom Functions

User copyright information (can be set in camera)
Image rating (0-5 stars)
GPS coordinates: Latitude, Longitude, Elevation, Coordinated Universal Time (UTC), Satellite signal acquisition status

Yes / Yes

Yes

No

Yes

1.5x - 10x

(1) Single image with information (2 levels)
(2) Single image
(3) 4 image index
(4) 9 image index
(5) 36 image index
(6) 100 image index
(7) Jump Display
(8) Movie/edit

Playback time: 1/2/3/5/10/20 seconds
Repeat: On/Off
Background music: On/Off
Transition effect: Off, Slide in 1, Slide in 2, Fade 1, Fade 2, Fade 3

Brightness: Yes
RGB: Yes

Yes

Erase: Single image, All images in folder, Checkmarked images, unprotected images
Protection: Erase protection of one image at a time

(1) Shooting menu (x5)
(2) Playback menu (x3)
(3) Setup menu (x5)
(4) Custom Functions menu
(5) My Menu

25 Languages
English, German, French, Dutch, Danish, Portuguese, Finnish, Italian, Norwegian, Swedish, Spanish, Greek, Russian, Polish, Czech, Hungarian, Romanian, Ukrainian, Turkish, Arabic, Thai, Simplified Chinese, Traditional Chinese, Korean and Japanese

Compatible satellites: GPS satellites (USA), GLONASS satellites (Russia), Quasi-Zenith Satellite System (QZSS) MICHIBIKI (Japan)16
Position update interval: 1 sec., 5 sec., 10 sec., 15 sec., 30 sec., 1 min., 2 min., 5 min.
Time setting: GPS time data set to camera
Log data: One file per day, NMEA format

Update possible by the user.

Hi-Speed USB (USB 2.0)

Wi-Fi (2.4GHz) Channels: IEEE802.11b, IEEE802.11g, IEEE802.11n17

Camera Access Point: WPA2-PSK with AES encryption or open
Infrastructure: Shared key, with WEP encryption, WPA-PSK/WPA2-PSK with TKIP/AES encryption or open

Bluetooth Specification Version 4.1 compliant (Bluetooth low energy technology)18

NFC Forum Type 3/4 Tag compliant (dynamic)

HDMI output (Type-C), External microphone (3.5 mm Stereo mini jack)

Canon Compact Photo Printers and PIXMA Printers supporting PictBridge

Yes (PictBridge via WLAN compatible)

SD, SDHC or SDXC (UHS-I) card

Windows 10 / 8.1 / 8 / 7 (With Microsoft .NET Framework 4.5 is installed)19
Mac OS X 10.9 / 10.10 / 10.11 / 10.12

Digital Photo Professional 4

EOS Utility
EOS Lens Registration Tool
EOS Web Service Registration Tool
EOS Sample Music
Picture Style Editor
Map Utility

Rechargeable Li-ion Battery LP-E6N (supplied)

Approx. 1200 shots (at 23°C, AE 50%, FE 50%)20
Approx. 1100 shots (at 0°C, AE 50%, FE 50%)

6 levels + percentage

Power turns off after 1, 2, 4, 8 or 15 mins.

AC Adapter AC-E6(N), DC coupler: DR-E6, Battery charger LC-E6E, Car Battery charger CBC-E6

Eyecup Eb, E-series Dioptric Adjustment Lens, Eyepiece Extender EP-EX15II, Angle Finder C

Protecting Cloth PC-E1

Built in Wi-Fi transmission

All EF lenses (excludes EF-S lenses & EF-M lenses)

Canon Speedlites (90EX, 220EX, 270EX, 270EX II, 320EX, 420EX, 430EX, 430EX II, 430EX III-RT, 550EX, 580EX, 580EX II, 600EX, 600EX-RT, Macro-Ring-Lite MR-14EX II, Macro Twin Lite MT-24EX, Speedlite Transmitter ST-E2, Speedlite Transmitter ST-E3-RT)

Battery Grip BG-E21

Remote Switch RS-80N3
Timer Remote Controller TC-80N3
Remote Controller RC-6
Wireless Remote Control BR-E1 (via Bluetooth)

Hand Strap E2
Interface Cable IFC-400PCU
Directional Stereo Microphone DM-E1

Chassis: Aluminum alloy and polycarbonate resin with glass fiber

Body: Polycarbonate resin with special conductive fiber & Polycarbonate resin with glass fiber on some parts

0 – 40 °C, 85% or less humidity

144.0 x 110.5 x 74.8 mm

Approx. 765 g
