Feature 1Stylish Design fuels the pleasure of ownership

Lightweight, durable aluminum body parts and synthetic leather covering enhance the feel of the camera in the hand, with texture that resembles genuine leather.

Three stylish configurations

A touch of the zoom ring lets you select any of three camera configurations. In portable mode, the lens retracts fully inside the body, minimizing camera size. In standby mode, the lens partially extends but remains closed. Then, with one more touch of the ring, activate the camera into shooting mode.

• Shooting Mode
• Standby Mode
• Portable Mode

Stylish quality design with leather and Aluminum

The harmony of aluminum and leather creates a unique impression of luxury.
In addition to its distinctive looks, the XF1 is also light-weight, durable, and a pleasure to hold.

3.0-inch Clear LCD with "Monitor Sunlight Mode"

When bright sunlight makes composing or viewing the monitor difficult, you can use the E-Fn button to easily switch to the "Monitor Sunlight Mode" Turn on the "monitor sunlight mode" by holding down the E-Fn button. Enjoy comfortable framing and review of shots on the large 3-inch high-contrast 460,000-dot LCD monitor made by tempered glass.

1. 1. FUJIFILM XF1
2. 2. Conventional Digital Camera

Enjoy dressing it up!

Feature 2Discover the beauty of f/1.8, at night, indoors, whenever light is low

The XF1's fast f/1.8 lens allows poorly-lit subjects to be photographed without raising sensitivity levels, keeping noise to a minimum. Its aperture of f/1.8 with a construction that features 7 lens elements in 6 groups. All elements are subjected to Electron Beam Coating process.

Fujinon lens with bright f/1.8 aperture produces stunning pictures in low light

The bright f/1.8 lens lets you capture quality pictures not normally possible with a compact camera. Noise is kept to a minimum without boosting sensitivity, while camera shake and subject motion are prevented due to high shutter speeds. And thanks to the large aperture, you can also create attractive "bokeh" blurred background effects.

Six-blade aperture diaphragm and 3cm macro

With a maximum aperture of f/1.8 at the wide angle setting and a six-blade aperture diaphragm, the XF1's lens delivers beautiful defocused blur. Together with macro capabilities to within just 3cm of your subject, that means huge photographic potential in a highly compact body.

New Fujinon f/1.8 lens: Compact size, superb quality

Featuring state-of-the-art technologies including aspherical elements and high refractive index glass, the XF1's lens boasts a fast f/1.8 maximum aperture and a slim profile that would be virtually impossible with conventional lens designs. Another important feature is Optical Image Stabilization, which shifts one group of four elements to minimize camera shake without compromising resolution around the edges of the image, a common problem with conventional stabilization systems.

All glass 6 groups/7 elements Configuration - 4 aspherical and 3 extra low dispersion lenses -

The slim-line lens achieves its aperture of f/1.8 with a construction that features 7 lens elements in 6 groups (4 aspherical and 3 extra low dispersion lenses)

Lens Construction

By using 4 high-performance aspherical lenses, the FUJIFILM XF1 delivers sharp image quality with rich resolution. These lenses also contribute to a more compact overall lens configuration.

1. 1. Focal Plane

• Spherical Lens
• Aspherical Lens

3 ED lenses have been employed for their low dispersion and effective reduction of chromatic aberrations. By preventing color fringing and reducing contrast, the FUJIFILM XF1 lens captures images with superb accuracy across the zoom range from wide angle to telephoto.
From wide angle to telephoto, and from the centre of the image to the edges, the FUJIFILM XF1's optical performance is designed to capture images with exceptional sharpness of detail and color fidelity in every scene.

• Conventional Digital Camera
• FUJIFILM XF1

Image stabilizer (Lens shift type)

With its built-in optical (lens shift type) image stabilization function the XF1 will correct your image for any blurring that occurs when photographing moving objects. You will get a clear image without blurring in all kinds of scenes.

High-Transmittance EBC

High Transmittance EBC (Electron Beam Coating) is FUJINON's unique wide-band technology developed for FUJINON broadcast-use lenses. The XF1 is the first compact camera to use the High Transmittance EBC for double sides of all glass lenses. Because highly refractive glass bends light rays more sharply than conventional optical glass, it creates greater potential for reflections which can cause ghosting and flare. HT-EBC technology effectively minimizes this stray light, assuring sharp, clear images under even the most demanding conditions.



Feature 3High Quality Photos & Movies with the EXR CMOS

Large sensor captures beautiful images, even in low light.

EXR AUTO 103 Shooting Patterns

EXR Auto with Motion Detection instantly recognizes 58 types of scene, automatically optimizes every setting from exposure to white balance, and switches to the ideal sensor mode for the scene and subject: HR High Resolution for well-lit conditions, SN High Sensitivity/Low Noise mode for low light, and DR Dynamic Range mode for high-contrast scenes.

Best Photo Shooting Anytime with Premium EXR AUTO

Advanced Anti Blur x SN

Beautiful hand-held night scenes

Frames captured with high-speed continuous shooting at high sensitivity are overlapped to create a single optimum image, keeping noise to an absolute minimum. Image blur is minimized, even when camera is hand-held.

Advanced Anti Blur

When shooting dark scenes, Advanced Anti Blur adds the power of EXR CMOS and Multi Frame technology to combine 4 frames into a single, sharp blur-free image with remarkably low noise.

Portrait and Motion x Greenery x HR

• Conventional Digital Camera
• FUJIFILM XF1

Moving subjects are crisp and clear

The FUJIFILM XF1 recognizes the background and identifies moving objects to optimize focus, brightness and other settings.

Portrait Backlit x Sunset x DR

• Conventional Digital Camera
• FUJIFILM XF1

Delivers the best results of the sunset as it intelligently recognizes the scene emphasizing the vividness of the colors and the depth of the scene with the EXR sensor mode automatically switched to Dynamic Range to capture the high contrast involved in the scene.

Advanced Scene Recognition

Full HD Movies NEW Movie Scene Recognition

The XF1 takes the guesswork out of recording movies with a new Movie Scene Recognition function. Automatically optimizing settings for a variety of shooting conditions, Movie Scene Recognition combines with Face Tracking AF to give you crisp, colorful HD movies with impressive stereo sound.

One Touch Movie Recording Button

A one-touch Movie Recording Button enables you to capture all the action in full HD.

Photo Shooting During Recording

Still photos can be captured during movie recordings.

• * The photo is saved separately from the movie and does not appear as part of the movie.

Film Simulation Setting

Manually select Film Simulation and produce various color expressions.

Large 12M 2/3-inch EXR CMOS Sensor adapts to ensure high quality images, whatever the situation

In the XF1, FUJIFILM brings its unique EXR CMOS pixel array to a larger 2/3-inch sensor. Because each pixel is larger, it can capture more light, dramatically reducing false color artifacts and noise at high sensitivities. Plus, thanks to further speed improvements in high-performance CMOS technology, you'll enjoy rapid continuous shooting as well as high-resolution video.



Feature 4Speed Response with EXR Processor

The EXR processor offers a fast AF in dark scenes.

Fast startup 0.55-second response means you'll never miss the moment

Quick, responsive AF, even in low light

Locking on to your subject in as little as 0.16 seconds, High Speed Contrast Detection AF captures even spur-of-the-moment shots with sharp clarity at maximum 4x zoom. And unlike conventional premium digital cameras, the XF1 autofocus system reacts quickly even in low light, making it possible to shoot high-quality hand-held photos indoors or at night.

Fast Startup 0.55 sec.

In QUICK START MODE, the XF1 is ready to shoot in just 0.55 seconds.

Shooting Interval 0.8 sec includes in AF.

From quicker startup to shorter shot-to-shot delay (minimum 0.8 sec. delay), the responsive EXR sensor and processor ensure you never miss a shot.

• * when QUICK START mode set to ON.

• ** The frame rate varies depending on the shooting conditions or numbers of frames in continuous shooting.

EXR Processor for superior resolution, wide dynamic range, high sensitivity, and low noise

Working in tandem with the 2/3-inch EXR CMOS sensor, the EXR processor helps take image quality to a new level. The fast, powerful twin CPU EXR Core is reconfigurable, meaning it instantly adapts to complex processing needs. The benefits: superb quality still photographs, rapid-fire continuous shooting, and true high-resolution video.



Feature 5Manual Zoom & effortless operation

Manual zoom lets you frame and compose as you like.

25-100mm* manual 4X optical zoom lens

• * 35mm format equivalent

Unlike power zoom, the XF1's zoom ring provides direct manual controls, keeping the zoom action very smooth. The 4x optical zoom is complemented by a super resolution digital zoom up to 8x.

Intelligent Digital Zoom

Digitally Double Your Zoom and Still Enjoy Excellent Resolution

For telephoto shots beyond the 4x optical zoom range, Intelligent Digital Zoom doubles your zoom to the equivalent of 8x zoom and delivers excellent sharpness and detail.

• Wide Angle (25mm*)
• 4x Optical Zoom (100mm*)
• 8x Intelligent Digital Zoom (200mm**)

• *: Equivalent on 35mm format
• **: Equivalent to angle of view on 35mm format

NEW Customized control: The E-Fn button

The E-Fn extended function button lets you customize your XF1 to offer immediate access to your most-used controls. One touch and the monitor displays a menu of six items of your choice. Full control, at your fingertips!

E-Fn button

• Custom screen
• Menu screen
• 1: Extended-function E-Fn button

Easy to master user interface

Quick-response command dial

The conveniently located Main Command Dial gives you easy access to Shutter Speed and Aperture settings.
2: Command dial

Histogram

Before shooting, the built-in histogram display provides an at-a-glance confirmation of brightness levels. Together with the exposure compensation dial on the top control deck, this tool makes it simple to confirm you have the right exposure setting, and take great photos.

Electronic Horizon Leveling Gauge

When composing a shot in the spacious LCD, the built-in electronic level display makes it easy to align the image with the true horizon.

Specifications

Model Name	FUJIFILM XF1
Number of effective pixels*1	12.0 million pixels
Image sensor	2/3-inch EXR CMOS with primary color filter
Storage media	Internal memory (approx. 25 MB) SD / SDHC / SDXC(UHS-I) memory card*2
File format	still image JPEG (Exif Ver 2.3)*3, RAW (RAF format), RAW + JPEG (Design rule for Camera File system compliant / DPOF-compatible) movie H.264 (MOV) with Stereo sound
Number of recorded pixels	L : (4:3) 4000 x 3000 / (3:2) 4000 x 2664 / (16:9) 4000 x 2248 / (1:1) 2992 x 2992 M : (4:3) 2816 x 2112 / (3:2) 2816 x 1864 / (16:9) 2816 x 1584 / (1:1) 2112 x 2112 S : (4:3) 2048 x 1536 / (3:2) 2048 x 1360 / (16:9) 1920 x 1080 / (1:1) 1536 x 1536 360° Vertical 11520 x 1624 Horizontal 11520 x 1080 180° Vertical 5760 x 1624 Horizontal 5760 x 1080 120° Vertical 3840 x 1624 Horizontal 3840 x 1080
Lens	name Fujinon 4 x optical zoom lens focal length f=6.4 - 25.6 mm, equivalent to 25 - 100 mm on a 35 mm format. full-aperture F1.8 (Wide) - F4.9 (Telephoto) constitution 6 groups 7 lenses (4 aspherical glass molded lenses included)
Digital zoom	Intelligent digital zoom approx. 2x (up to 8 x when combined with optical zoom)
Aperture	F1.8-F11(Wide) F4.9-F11(Telephoto) 1/3EV step (controlled 6-blade aperture diaphragm)
Focus distance (from lens surface)	Normal Wide : Approx. 50 cm / 1.6 ft. to infinity Telephoto : Approx. 80 cm / 2.6 ft. to infinity Macro Wide : Approx. 3 cm - 3.0 m / 1.1 in. - 9.8 ft. Telephoto : Approx. 50 cm - 3.0 m / 1.6 ft. - 9.8 ft.
Sensitivity	Auto / Equivalent to ISO 100 / 200 / 250 / 320 / 400 / 500 / 640 / 800 / 1000 / 1250 / 1600 / 2000 / 2500 / 3200 / 4000* / 5000* / 6400* / 12800* (Standard Output Sensitivity) * ISO4000 / 5000 / 6400 : M mode or lower, ISO12800 : S mode
Exposure control	TTL 256-zones metering, Multi / Spot / Average
Exposure mode	Programmed AE, Aperture Priority AE, Shutter Priority AE, Manual
Shooting modes	SP Natural Light, Natural Light & Flash, Portrait, Portrait Enhancer, Landscape, Sport, Night, Night (Tripod), Fireworks, Sunset, Snow, Beach, Party, Flower, Text, Underwater MODE DIAL EXR, AUTO, P, S, A, M, C1, C2, Movie, SP, Adv.
Image stabilizer	Lens shift type
Exporsure compensation	-2.0EV - +2.0EV 1/3EV step
Shutter speed	(Auto mode) 1/4 sec. to 1/2000* sec., (All other modes) 30 sec. to 1/2000* sec. * 1/2000 sec. at small aperture, 1/1000 sec. at full aperture
Continuous shooting	TOP Super High : approx. 10 fps (Size M, S) High : approx. 7 fps (Size L, M, S) Middle : approx. 5 fps (Size L, M, S) Low : approx. 3 fps (Size L, M, S) *SD memory card with a class 4 write speed (4 MB/sec.) or better is recommended. *The frame rate varies depending on the shooting conditions or numbers of frames in continuous shooting. others Best Frame capture : Super High : approx. 10 fps 8 / 16 frames (Size M, S) High : approx. 7 fps 8 frames (Size L, M, S) / 16 frames (Size M, S) Middle : approx. 5 fps 8 frames (Size L, M, S) / 16 frames (Size M, S) Low : approx. 3 fps 8 frames (Size L, M, S) / 16 frames (Size M, S)
Auto bracketing	AE Bracketing : ±1/3EV, ±2/3EV, ±1EV Film Simulation Bracketing : PROVIA / STANDARD, Velvia / VIVID, ASTIA / SOFT Dynamic Range Bracketing : 100%, 200%, 400% ISO Sensitivity Bracketing : ±1/3EV, ±2/3EV, ±1EV
Focus	mode Single AF / Continuous AF, Manual AF (One-push AF mode included) type TTL contrast AF, AF assist illuminator available AF frame selection Multi AF, Area AF, Tracking AF
White balance	Automatic scene recognition Preset : Fine, Shade, Fluorescent light (Daylight), Fluorescent light (Warm White), Fluorescent light (Cool White), Incandescent light, Underwater, Custom, Color temperature selection
Self-timer	10 sec. / 2 sec. delay
Flash	Auto flash (super intelligent flash) Effective range : (ISO AUTO (800)) Wide : Approx. 50 cm - 7.4 m / 1.6 ft. - 24.2 ft. Telephoto : Approx. 80 cm - 2.7 m / 2.6 ft. - 8.8 ft.
Flash modes	Red-eye removal OFF : Auto, Forced Flash, Suppressed Flash, Slow Synchro. Red-eye removal ON : Red-eye Reduction Auto, Red-eye Reduction & Forced Flash, Suppressed Flash, Red-eye Reduction & Slow Synchro.
Hot shoe	-
Viewfinder	-
LCD monitor	3.0-inch, approx. 460,000 dots, color LCD monitor, approx. 100% coverage
Movie recording	1920 x 1080 pixels / 1280 x 720 pixels / 640 x 480 pixels (30 frames / sec.) with stereo sound Optical zoom (manual) can be used.
Photography functions	EXR mode (EXR Auto / Resolution priority / High ISO & Low noise priority / Dynamic range priority), Face recognition, Face Detection, Auto red-eye removal, Film simulation, Framing guideline, Frame No. memory, Histogram display, Best frame capture, Advanced mode (Advanced filter, Motion panorama360, Pro focus, Pro low light, Multiple exposure, Individual shutter 3D), High Speed Movie (70 / 120 / 200 frames/sec.), Electronic level, Advanced Anti Blur, Date stamp, Recording movie in the EXR Auto mode：Automatic Scene Selection. (Auto, Macro, Landscape, Night, Portrait, Portrait+Night, Backlight Portrait), E-fn (extended function) BUTTON CUSTOM SETTING
Playback functions	Face Detection, Auto red-eye removal, Multi-frame playback (with micro thumbnail), Protect, Crop, Resize, Slide show, Image rotate, Voice memo, Histogram display, Exposure warning, Photobook assist, Image search, Favorites, Mark for upload, Panorama, Erase selected frames, RAW conversing
Other functions	PictBridge, Exif Print, 35 Languages, Time difference, Silent mode
Terminal	Video output NTSC / PAL selectable with Monaural sound Digital interface USB 2.0 High-Speed HDMI output HDMI Mini connector
Power supply	NP-50A Li-ion battery (included) CP-50 with AC power adapter AC-5VX (sold separately)
Dimensions	107.9(W) x 61.5(H) x 33.0(D) mm / 4.2(W) x 2.4(H) x 1.2(D) in.
Weight	Approx. 225 g / 7.9 oz. (including battery and memory card) Approx. 204 g / 7.1 oz. (excluding battery and memory card)
Operating Temperature	0°C - 40°C
Operating Humidity	10% - 80% (no condensation)
Guide to the number of available frames for battery operation	approx. 300 frames CIPA standard
Accessories included	Li-ion battery NP-50A Battery charger BC-50B Hand strap Lens cap USB cable CD-ROM (Viewer software, RAW File Converter etc.*4 ) Owner's manual
Optional accessories	Li-ion battery NP-50 Battery charger BC-45W A / V cable AV-C1 Soft case SC-XF DC coupler CP-50 AC power adapter AC-5VX

• *1 Number of effective pixels: The number of pixels on the image sensor which receive input light through the optical lens, and which are effectively reflected in the final output data of the still image.
• *2 Please see the Fujifilm website to check memory card compatibility.
• *3 Exif 2.3 is a digital camera file format that contains a variety of shooting information for optimal printing.
• *4 OS compatibility
  Viewer software: Windows 8 / Windows 7 / Vista / XP, Mac OS X 10.5-10.6
  RAW File Converter: Windows 8 / Windows 7 / Vista / XP, Mac OS X 10.5-10.7

Memory Card Capacity and Image Quality / Size

Number of images

Modes		Still image (L)
Number of recorded pixels		4000 x 3000 (4:3)		4000 x 2664 (3:2)		4000 x 2248 (16:9)		2992 x 2992 (1:1)
Quality		JPEG FINE	JPEG NORMAL	JPEG FINE	JPEG NORMAL	JPEG FINE	JPEG NORMAL	JPEG FINE	JPEG NORMAL
SDHC memory card	4 GB	800	1260	900	1410	1060	1670	1060	1670
	8 GB	1590	2520	1800	2820	2120	3320	2120	3320

Number of images

Modes		Still image (M)
Number of recorded pixels		2816 x 2112 (4:3)		2816 x 1864 (3:2)		2816 x 1584 (16:9)		2112 x 2112 (1:1)
Quality		JPEG FINE	JPEG NORMAL	JPEG FINE	JPEG NORMAL	JPEG FINE	JPEG NORMAL	JPEG FINE	JPEG NORMAL
SDHC memory card	4 GB	1280	2460	1450	2800	1690	3260	1690	3260
	8 GB	2550	4890	2880	5570	3370	6470	3370	6470

Number of images

Modes		Still image (S)
Number of recorded pixels		2048 x 1536 (4:3)		2048 x 1360 (3:2)		1920 x 1080 (16:9)		1536 x 1536 (1:1)
Quality		JPEG FINE	JPEG NORMAL	JPEG FINE	JPEG NORMAL	JPEG FINE	JPEG NORMAL	JPEG FINE	JPEG NORMAL
SDHC memory card	4 GB	2360	4460	2620	5020	3440	5020	3090	5740
	8 GB	4700	8870	5210	9980	6850	9980	6140	11410

Number of images

Modes		Still image (RAW)
SDHC memory card	4 GB	200
	8 GB	390

Recording time

Modes		Movie*5
Number of recorded pixels		Movie recording time
Quality		FULL HD (1920 x 1080)*6	HD (1280 x 720)*6	VGA (640 x 480)*7
SDHC memory card	4 GB	37min.	47min.	1hr. 52min.
	8 GB	1hr. 14min.	1hr. 35min.	3hr. 43min.

• *5 Use a card or better when shooting HD movie and High speed movie.
• *6 Individual movie files cannot exceed approx. maximum 29 minutes.
• *7 Individual movies files cannot exceed approx. maximum 120 minutes.
