1. Wide view angle IPS Screen, High resolution 1280x800, bright, colorful display
2. The enhanced 400cd/m² backlight and 800:1 color contrast ratio
3. Slim design 17mm, Portable Light compatible for Steadycam, DSLR Rig, Camcorder Kit, HandheldStabilizer, Video Camera Crane
4. Inputs: HDMI, AV, Wire remote OSD controller; Outputs: Built-in Speaker, 3.5mm Audio
5. Special Features:
* Peaking Focus Assist (1. Red highlight over parts of the image in focus; 2. Red highlight over parts of the monochrome image in focus)
* Brightness Histogram
* False Colors
* Exposure (zebras)
* Check Field (Red, Green, Blue, Mono)
* Camera Mode
* Pixel to Pixel
* Center Marker
* Safe Marker (80%, 85%, 90%, 93%, 96%, 2.35:1)
* Image Flip (Horizontal, Vertical, Hor&Ver)
* Image Freeze
* Zoom All
* U/D & L/R Zoom
* Custom Color Temperature
Display Spec.
Model |
FW759P |
Screen Size |
7" IPS |
Resolution |
1280×800 pixels |
Dot pitch |
0.11775(H) × 0.11775(V) mm |
Aspect Ratio |
16:10 |
Brightness |
400cd/m² |
Contrast Ratio |
800:1 |
Backlight |
LED |
Viewing Angle |
89°/89°(L/R) 89°/89°(U/D) |
Input
1 X HDMI |
HDMI |
1 X AV |
AV |
1 X OSD controller |
Wire remote OSD controller |
Audio
Audio Out |
Stereo Headphone, Speaker |
HDMI Support Format
480i/576i/480p/576p |
1080i (60/59.94/50) |
720p (60/59.94/50/30/29/25/24/23.98) |
1080p (60/59.94/50/30/29.97/25/24/24sF/23.98/ 23.98sF) |
General
Input Voltage |
DC6.5~35V |
Power Consumption |
≤5W |
Power Connector |
DC |
Battery Plate |
F970 (Standard); D28S, LP-E6 (Optional) |
Working Temperature |
-20°C~50°C |
Storage Temperature |
-30°C~60°C |
Install Way |
1/4"-20 Thread Socket (1 bottom side) |
Unit Size |
176L×130H×17D (mm) |
Unit Weight |
300g |
